Light Bee S

Based on the popular Light Bee X, the S model is aimed at youth aged 10 and up. It features MX-style suspension, 17-inch wheels and a 48V removable lithium battery pack.

Anytime, Anywhere

From mountaintops to valleys, from the track to the trails, your Light Bee S can take you to anywhere you want. It's easy and fast to recharge, too.

Improve Your Riding Skills

Easy to ride, the Light Bee S is a perfect stepping stone to larger electric bikes. Ride easy and free without worrying about gears, and focus only on the riding itself. That’s your Light Bee S.

Excellent Performance and Great Manoeuvrability

With a friendly ECO mode and peak torque output of 220 Nm in Sports mode, new riders can go faster as they learn. With 17-inch wheels and knobby tires, the Light Bee S gives you great manoeuvrability all the time.

*Unless otherwise noted, ALL products sold from Sur Ron™ and authorized dealers are sold with the sole intention for off road or race track use only. This product or products may not comply with some State, Federal, Provincial and/or Local laws, ordinances, regulations. The buyer takes full responsibility of the use of these products on their vehicle which may or may not conform to all applicable laws and regulations for on road or highway use.


MSRP: 13800AED


  • Specially-Designed Single-Crown Inverted Fork

    Designed just for the Light Bee S, the front fork has 150mm of travel and adjustable rebound to suit varying road conditions. Feel comfortable and confident on any surface.

  • Adjustable, Lightweight Rear Suspension

    The multi-link TR rear suspension features a monoshock design, 75mm of travel and adjustable compression to tackling whatever terrain you encounter.

  • Easy To Handle, Fun To Ride

    With excellent ground clearance and a short wheelbase, the Light Bee S will spark both confidence and joy. When you're ready, choose Sports mode and twist the throttle to feel the power!

MOTOR
Motor Type:

PMSM

Mounting Position:Mid
Weight / Motor External Diameter:7.0kg / 180mm
Motor Axial Length:130mm
Peak Efficiency:95.60%
Cooling Method:Air-Cooled
CONTROLLER
Controller Type:

FOC SQUAREWAVE CONTROLLER

Dimensions:240mm x 110mm x 50mm
Traveling Wave Current / Highest Work Temperature:

70A / 100 °C

MOTOR POWER SYSTEM
Rated Voltage:48V (DC)
Rated Power / Peak Power:

2KW / 2.9KW

Rotation Speed:

5,000rpm

Road Legal:No
TRANSMISSION
Gear Ratio:

1: 9.18

Transmission:Belt & Chain
ELECTRICAL COMPONENTS
Battery:

48V20A LITHIUM BATTERY WITH 112 CELLS

VEHICLE
Frame:

Forged aluminum

Chassis Weight:

7.8KG

Chassis Surface & Colour Processing:Painted
Wheel Type & Size:

17 x 1.4 Wire-Spoke Aluminum Wheels Front & Rear

Tire Size:

70/100-17 Front & Rear

Max. Range:

70km @ 20km/h

Net Weight:

48kg

Vehicle Dimension:

1,820mm x 730mm x 1,020mm

Seat Height:760mm
Wheel Base:

1,250mm

Handlebar Width:

720mm

Available Colours:Black, Red, Blue
Charger:

5Ah

Charging Time:

4-4.5 hours

Front Suspension: KKE fork

Rear Suspension: KKE Monoshock With Intersect TR Suspension System

Brakes:

Bilateral 4-piston calipers, hydraulic disc brakes

Maximum Load:

75kg

Max. Climbing Angle:

25 degrees

Minimum Ground Clearance:

220mm

Speedometer:

LCD Digital Speedometer
